SMPB8300 / H Series Digital Pressure Transmitter 24VDC Power Supply Plastic
Contact Person : Ina Chen
Phone Number : 0086-15168536055
WhatsApp : +8615168536055
| Minimum Order Quantity : | 20 | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice | Delivery Time : | 5 - 30 Work Days |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | Negotiation |
| Place of Origin: | China | Brand Name: | Mkfale |
|---|---|---|---|
| Model Number: | SMAPB8010 |
|
Detail Information |
|||
| Proof Pressure: | 150 % F S | Operating Temp: | - 20 To +85 ℃ |
|---|---|---|---|
| Process Connection: | 1/4NPT Male Or 1/8NPT Male | Wetted Parts: | SS304 |
| Housing Material: | Plastic | Power Consume: | < 0.5W ( 24VDC ) |
| Highlight: | pressure transmitter with display,differential pressure transmitter |
||
Product Description
High Precision Digital Pressure Transmitter SMAPB8010 Series With Wide Measuring Range
Technical Specification Table
|
SMAPB SERIES PRESSURE TRANSMITTER |
SMAPB8010 |
| Accuracy | 0.5%F S,1%F S,5%F S(including linearity.Hysteresis and repeatability) |
| Measuring Range | 0... 1bar to 0... 25bar |
| Response time | ≤10ms |
| Power supply | 24VDC (or 12 to 36VDC) |
| Output | 4 to 20mA 2-wires |
| Load(Ω) | ＜(u-12) / 0.02A |
| Proof pressure | 150%F S |
| Burst pressure | 300%F S |
| Operating Temp | -20 to +85℃ |
| Storing Temp | -40 to +125℃ |
| Process connection | 1/4NPT male or 1/8NPT male |
| Wetted parts | SS304 |
| Housing material | Plastic |
| Power Consume | <0.5W(24VDC) |
| Weight | 110g |
Why choose us
1: Sample order & small quantity order is acceptable .
2: Customize according to your special request .
3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee
FAQ
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
